1. Introduction

This chapter focuses on the 18 bit Navy computers which were eventually replaced by 16 bit computers or display embedded systems. The first unit isn't illustrated on the genealogy chart, i.e. the 1218 brass board was called the Computer Unit Tester (CUT) , whose logic design was created using circuit card types from the CP-642A in order to effect more efficient testing of UNIVAC commercial and NTDS peripheral equipments.  An innovation of these units was the Input/output (I/0) channels. They could be configured to operate in a normal 18 bit length or an odd/even pair could be ganged into a 36 bit I/O channel. With the double length, peripheral equipments with either 30 or 36 bit word lengths as well as the 8-bit, 6 bit, and 5-bit simple units could be tested.
The Defense computers were programmed using the Trim III assembler while the commercial software was developed with a COBOL compiler. [lab]

 July 2017 ANNOUNCEMENT: My name is Duane Craps. I worked at the Norfolk Naval Shipyard on Naval Missile Systems which used 1219B [CP-848/UYK] computers which were also known as the MK-152 Digital Fire Control Computers. I am involved in the restoration of the 1219B's at the Vintage Computer Federation museum at Wall, NJ. These 1219B computers were formerly at Johns Hopkins University Applied Physics Laboratory where they were used in research for the Navy's Missile Program.
I had a Yahoo! group for UNIVAC Computers until Yahoo closed their groups : The files are now on my MeWe computer group  files area: https://mewe.com/group/5fd552d31f79902b9084908f/documents.  In the 1219B/CP848/mk152 folder then the 1219 emulator folder Link to the home page: https://mewe.com/group/5fd552d31f79902b9084908f. The emulator EXE and  the memory.0 needs to be in the same folder. The NUMB2OCT.ttf font needs to be installed in host computer to display the octal registers as blinking lights. Richard Carlson on the MeWe group is building beautiful simulators for the 1219B and 1218 that use the UNIVAC logic down to the gate level, but run too slowly.  Mine is written in Visual Basic. I just do the math and plug the results into the registers. Direct any questions to the MeWE group. Link to video at the museum: https://www.facebook.com/vcfederation/videos

You 18-bit guys would be happy to know that the last Navy 1219Bs were just turned off in 2015! They were at a shore site AN/SPN-42 Automatic Carrier Landing System. If you find any 1218/1219/418 information please let me know. Duane

2. Computer Family 18-bit geneology

This 1968 genealogy clip shows the commercial units in red, the defense in blue and a couple of airborne units in yellow.  According to the Univac Products St. Paul, Volume II printed in 1961, the 4 of the 418 type number was because of a 4 microsecond memory speed and the 18 because of the digital word length.

Harry Wise commented, "The 18 bit line really got its start when Univac sold the 418 bit architecture to Westinghouse for them to brand as the Westinghouse Prodac 510 and Prodac 580. They were the same machine with fewer options in the 510. Many of the cards in the Prodac machines were labeled “418”."

The first 580 was delivered in 1962 as shown in this photo, scanned at the Lawshe Memorial Museum in November, 2023 by Keith Myhre.

The 18 bit machines discussed hereunder were a 'commercial-to-military' ISA transition. The series was the Computer Unit Tester, the commercial 418, and then the 1218.  The 418 commercial line became the 418 I, 418 II, and 418 III as new technologies and features were incorporated.

3. Computer Descriptions

There were about 950 computers delivered with the basic 18 bit architecture - not counting any commercial 418 series computers. The basic Instruction Set Architecture for this series came from the Computer Unit Tester (CUT), a laboratory unit initially assembled using printed circuit cards from the CP-642A. Manufacturing test engineers need to be able to test the interfaces of peripheral devices with a variety of word lengths; the 1100 series 36 bit machines down to the 6 bit 1232 I/O Console. The CUT characteristics were 18 bit instruction, 8 microsecond 16k word core memory, eight duplexer I/O channels - Type A per DS4772 (-15v) with a rate of 62.5 Kwords per second. The unit cabinet took 25.5 cu. ft, weighed 900 lbs, and consumed 1000 watts. [written by Lowell with inputs from Don Mager.]

{Nov. 2020 add in}  Don: Do you have any recollections, what was the first Navy application of the 1218 (CP-789)?  It is interesting that the CP788 (1215) digital trainer had a government nomenclature before the 1218.  Our records show that the 1st CP-789 was delivered in April 1963 and that ARTS I used 1218s in 1965.
Sorry, don't know the answer. But, you may be interested in knowing that one of the first 1218's was used by Jet Propulsion Labs for telemetry data processing for the Appolo program. After they got it, they made some changes in the I/O logic which resulted in a "once a day" type fleeting glitch. Glen Kregness and I both carefully looked-over the changes they had made and could not see anything wrong. The problem continued and so, I went to JPL, circa 1963, and after a couple days trying to track-down the problem, I proposed a logic change which I thought might solve the problem. Glen and Hy Osofsky both agreed that my proposed logic change should at least not cause some other problem. So, while still at JPL, I installed the change and the problem disappeared - what a relief! The story does not quite end there.
Several months later, JPL moved the project to Cape Kennedy and one day I get an urgent call from Red Phillips to get down to JPL at Cape Kennedy. According to Marketing, they are having a problem again. When I get to the site, the JPL guys greet me with "what are you doing here?" I explain that I hear they are having a problem again. Their answer was an empathic "No, it's working great!" By now I was getting to know the JPL guys quite well. They told me about how back at the lab they had been kidded by fellow employees for having bought the Univac 1218 because of reverse psychology. They said that after they sent-out RFP's to various computer companies, other's responded with thick brochures and proposals. Univac came back with a 2-page description of the 1218 and a note saying, "contact us if you're interested" - and they never regretted their decision. Later that day they invited me to a barbeque with them and their families and then to jai alai games in the evening. Mission accomplished - fun! Don Mager

3.1 The 1218 (CP-789)

The CP-789 became the core of the Navy's on board Management Information System to keep track of all the logistics such as ammunition, foodstuffs, etc. A variation with more memory was designated the AN/UYK-5 (Moonbeam) that used special software to provide on ship logistic management. [lab]

1218 Characteristics - project start October 1962:

18 bit word size, memory capacity from 4k words to 32k words with a 4 microsecond cycle time. Data size was either 18 or 36 bits [i.e. dual word] There were 98 instructions with a basic add time of 8 microseconds. A maximum of 8 I/O channels with -15V interface were available.

AN/UYK-5 ( )

A version of the 1218 was sold to the USMC for their 'Landing Approach System-3', the first delivery was Oct. 23, 1965. [lab]

UNIVAC U1500

A system - Based on the Univac 418 design, the 1218 came with COBOL, very necessary for the software development. This system used for inventory control was developed for the AFS-1 through -7, the MARS Class Combat Stores Ships. John Markfelder, Univac headquarters marketing, Skip Wren in D.C. were the primary customer contacts. The system consisted of the 1218, a 1232 paper tape and typewriter unit, the 1240 magnetic tape unit, and the Card Reader, Punch Interpreter (CRPI) unit. The CRPI was the 'old' John Bull taper pin punch/reader which had previously been used with the Mod 0 file computer. Based on user feedback, the unit should have been called CRaP because the I portion didn't work very well. [Lyle Franklin]

Hi Lowell: I was the program manager at DCS/Air at HQ-MC responsible for introducing the U-1500 into all Marine Air groups. After I retired from the USMC, I assisted John Markfelder in the UNIVAC deliveries to the Marines as well as responding to their customer problems world wide. [Earl Lillestrand]

From Ron Q. Smith - Subject: UNIVAC 1218 in Australia - A UNIVAC 1218 was used at the Honeysuckle Creek tracking station. http://www.honeysucklecreek.net/station/technical.html

3.2 The 1219B (CP-848)

The CP-848 became the base computer for TARTAR, TALOS, and TERRIER missile launching from ship installations. The government nomenclature for those systems was MK-152. These units required a motor generator for power. [lab]

1219B Characteristics - project start July 1967:

18 bit word size, memory capacity from 32k words to 65k words with a 2 microsecond cycle time. Data size was either 18 or 36 bits [i.e. dual word] There were 102 instructions with a basic add time of 2 microseconds. A maximum of 16 I/O channels with -15V or -3v interfaces available in four channel groups. First delivery was March 1968. [lab]

[5/20/2017] Lowell: We have recently scanned and uploaded to bitsavers.org The 1219B Logic Prints and the diagnostic manuals. Along with the 1219 FACT test information and Student Guide that I found some time ago. http://bitsavers.trailing-edge.com/pdf/univac/military/1219/ Duane  sdɐɹɔ ǝuɐnp

3.3 1219C

As the first CP-890 was in initial debug and test, a small team put together a proposal to use the card and cabinet packaging style with a 1 microsecond memory to develop a next generation 18 bit computer, tentatively to be identified as the UNIVAC type 1236 (1219C). This was a 'concept' computer, never designed nor built. The target market was the Sea Sparrow, to be bid exclusively with Sperry to Navord. The characteristics were to be either 15.1 or 11.6 cu. ft, 900 or 550 lbs, 2330 or 925 watts depending upon the size of the 131k memory or 32k memory capacity.

Lyle Franklin of Marketing, Ernie Lantto of Engineering and Curt Christensen of Program Management were the principals of this proposal. Raytheon won that competition. As part of the debriefing, Lyle Franklin told NAVORD: 'Perhaps I'll come back with a 16-bit computer proposal.' A prophecy which came true a year later when the 1616, UYK-15 was proposed for the ITT Gilfillan 'Fog Cutter' application. [Item written by Lowell with inputs from Lyle Franklin and Curt Christensen.]

3.4 1818/ILAAS

ILAAS was an airborne 18-bit machine using mechanical technologies from the CP-823 30-bit computer. The characteristics were a 2 microsecond memory in 4k to 32k words. This unit had only 27 instructions with 3 index registers mapped onto core addresses. It also had just 9 interrupts and 1 Real time clock. It had an Assembler and Utility Package. The Instruction Set Architecture differed significantly from other UNIVAC machines of the time in that bit 0 of the registers was at the left and bit 17 at the right. There were 5-bits for the instructions versus 6 bits in other machines. there were just 2 bits for index registers versus 3 bits.
Project start was March 1966, first delivery in May 1967. Gary Bosworth, Barbara Halvorson, and Lee Sheldon were engineers on this project. [lab]

3.5 CP-914, 1819

The CP-914 was another 18-bit airborne computer - using Alex Trumble Relay (ATR) chassis mechanical packaging similar to the 1830 Phoenix. These units had a 2 microsecond memory, three index registers and a real time clock. Two of these units were sold to Sperry Flight Systems, the first delivered July 2nd of 1973.
Project start was August 1968, first delivery in February 1969. [lab]

3.6 AN/UYK-11

This was/is the Minuteman missile launch computer. These were mounted in radiation hardened operations rooms and connected to missiles. These machines ran continuously running test programs to assure the readiness of the missiles for launch. Because of their design and benign environment, some of these units operated for over 5 years seven days a week, 24 hours per day without experiencing a hardware failure. This computer model had a unique red/black separation Input/Output section design to separate classified targeting information from status reporting channels. This unit used the same basic 18-bit instruction set, however it was mapped onto a 36 bit hardware structure. It also used a plated wire memory because there was a radiation hardening requirement that core memory and mated film memory couldn't meet. There is more about plated wire in the Engineering, Memory section. Project start was May 1969, first delivery October 5th 1971. [lab]

From: Wes Peters - 19 January 2009 via web site e-mail. Message:
The 18-bit computer page doesn't mention the FORTRAN IV compiler that was used to develop the Minuteman Operational Targeting Program as a part of the Rapid Retargeting upgrade for Minuteman II and III, and later used for the Peacekeeper Operational Targeting Program when Peacekeeper missiles were installed in Minuteman silos at F. E. Warren AFB. The Fortran compiler was hosted first on Univac 1108, and later on DEC VAX/VMS hosts. I worked on a static analysis package for this compiler as part of the MOTP ARSIP upgrade when I graduated college in 1984, and later was the developer test lead for Peacekeeper Operational Executive Program, the operating system that ran on the AN/UYK-11 in the Peacekeeper Launch Control Facilities.
Feel free to contact me if you'd like more details about the swan song of the AN/UYK-11, or as we affectionately knew it, the "Wicked Slow Computer." Top

3.7 The 418 Computer Series

We received 418 and 1219 computer comments from Montana, New Jersey, and Sweden then put together an 18bit computer ' Article for the Month'. When he read the article, Ben Manning wrote "Hey Lowell, I worked on 418 III's for 4 or 5 years, in the UK on a system for Joseph Lucas and then in Bluebell on the LEAP Law Enforcement system. I think I finally junked all my archival stuff during our last move on Dec 2014. I had all the system documentation, plus the instruction card for the 418 III but it is probably gone. Cheers!! Ben

{Editor's note: A 418 repertoire card image is included in the Eighteen Bit Computers article.}

4. Repertoire Cards

Many people gave repertoire cards to the Legacy Committee. Keith Myhre scanned the cards before they were donated to the Charles Babbage Institute. The 18-bit cards are linked hereunder.

 4. Technical Manuals
